Lutron Digital Multimeter (DM-9961) Inductance, Capacitance & Resistance

The Lutron DM-9961 is a compact, high-accuracy digital multimeter featuring a 4000-count display, auto-ranging capability, and comprehensive electrical measurement functions. Suitable for home electrical work, industrial service, and field troubleshooting, it measures voltage, current, resistance, frequency, capacitance, temperature, continuity, and diodes with dependable accuracy. Its backlit LCD and simplified control layout make it easy to operate in a wide range of environments.

• 4000-count high-resolution display: Clear, easy-to-read backlit LCD.
• Auto-range selection: Automatically selects the optimal measurement range for speed and accuracy.
• Comprehensive measurement capability: DCV, ACV, DCA, ACA, resistance, capacitance, frequency, temperature, continuity, and diode test.
• Safety compliance: Rated to IEC 61010 and CAT III 600 V.
• Auto power off: Extends battery life during field use.
• Built-in support stand: Allows hands-free operation on the bench or in the field.
• Rugged, compact housing: Lightweight and durable for routine electrical and electronic servicing.

General Specifications

• Display: 4000-count backlit LCD.
• Sampling time: Approx. 0.4 seconds.
• Operating temperature: 0°C to 50°C (32°F to 122°F).
• Operating humidity: Less than 80% RH.
• Power supply: One 9-volt battery (006P).
• Power consumption: Approx. 2 mA DC.
• Dimensions: 151 × 74 × 31 mm (5.94" × 2.91" × 1.22").
• Weight: Approx. 220 g (0.49 lb.).
• Safety rating: IEC 61010; CAT III 600 V.

Electrical Specifications (Condensed)

• Voltage: DCV up to 600 V; ACV up to 600 V.
• Current: DCA and ACA up to 10 A (fused), including mA and µA precision ranges.
• Resistance: Up to 40 MΩ.
• Capacitance: Up to 100 µF.
• Frequency: Up to 10 kHz.
• Temperature: −20°C to 1000°C (−4°F to 1832°F) with included thermocouple probe.
• Continuity & Diode: Audible continuity beeper and diode junction voltage measurement.

Included Items

• Red and black test leads (1 pair).
• K-type thermocouple temperature probe.
• Protective rubber holster.
• Instruction manual.

Optional Accessories

• Extended-range thermocouple temperature probes.
• Clamp-on ACA/DCA adapters.
• High-voltage test probes.
