Reference only — this item is no longer available. This product has been discontinued and cannot be ordered. We keep the page online so the specifications and documentation stay available to anyone still running the equipment. Current replacements are listed further down.

Discontinued

Talentum Flame Sensor Test Unit (1800-101) Flame Detector Tester

Reference only — not for sale

Model	1800-101
Manufacturer	FFE UK
Category	Fire and Smoke Safety
Status	Discontinued

Browse all Fire and Smoke Safety Ask us for a replacement

Product details (archived)

The information below is retained for reference only. This item is discontinued and cannot be ordered.

Talentum Flame Sensor Test Unit (1800-101) Flame Detector Tester

The 1800-101 is a Portable Test Unit Simulated Flame Detector Test Unit which comes with a rechargeable battery pack charger.

This Test Unit can also be used to recalibrate the solar blind ratio of a Talentum flame detector by using the calibration kit.

This test unit has been designed to generate a wide range of optical output signals. Flame sensors for fire detection and flame monitoring applications can be activated and tested. Most optical flame sensors respond to Ultra Violet (UV) and or Infra Red (IR) radiation emitted from flames during combustion. Many sensors also use flame flicker techniques to distinguish between flames and other optical false sources.

The test unit simulates the flickering flame signal by modulating the output of a filament lamp. The thermal time constant of a filament lamp prevents the generation of a perfect flame flicker signal. The slow response of the filament lamp will mean that some flame sensors many require more time to activate under test than they would with a real flame.
