TPI Dual Input K-Type Thermocouple Thermometer with Field Calibration (343C4)

TPI Dual Input K-Type Thermocouple Thermometer with Field Calibration (343C4)

The TPI 343 is a Dual Input K-Type Thermocouple Thermometer with Field Calibration and a -58 to 2,462 °F (-50 to 1,350°C) temperature range.

This configuration (343C4) is: Dual input K-type with two GK13M, one FK11M, one CK11M and A901CP carrying case.

• Auto Field Calibrate in less than 10 seconds in ice water to achieve +/- 1°F system (tester & probe) accuracy within 30°F to 120°F temperature range.
• Temp1, Temp2, Temp1-Temp2 display modes.
• Min / Max Record.
• Auto Resolution (0.1° / 1°).
• C/°F Selectable.
• Hold feature freezes reading on display.
• Auto Off.
• Protective rubber boot.
• Easy to read LCD display.

Specifications

• Input: Dual K-type Thermocouple.
• Temperature Range: 0.1°C/°F : up to 999.9°C/°F 1.0°C/°F : above 1,000°C/F.
• Display: 0.1°C/°F : up to 999.9°C/°F 1.0°C/°F : above 1,000°C/F.
• Accuracy: ±3°F(±1.6°C) from: -58°F to 32°F (-50°C to 0°C)±0.3% of rdg +1.8°F (1°C) from: 32°F to 1,100°F (0°C to 600°C)±0.4% of rdg +1.8°F (1°C) from: 1,100°F to 2,462°F (600°C to 1,350°C).
• Update Rate: 2.5 times/second.
• Key Buttons: On/Off, T1, T2, T1-T2, °C, °F, HOLD.
• Field Calibration: By key operation.
• Operating Temperature: 32°F to 122°F (0°C to 50°C).
• Storage Temperature: -13°F to 158°F (-25°C to 70°C).
• Battery: 9V.
• Battery Life: 200 hours (Alkaline).
