UEI Combustion Analysis Meter (SMARTBELL) CO2, O2 & Efficiency

Reference only — not for sale

Model	SMARTBELL
Manufacturer	UEI
Category	Leak Detectors
Status	Discontinued

Browse all Leak Detectors Ask us for a replacement

Traditional methods using “dumbbell” shakers often take 15 to 20 minutes to perform and only provide a snap shot of a system’s performance. Once adjustments are made the process needs to be repeated to verify that the corrections achieved the desired result. Don’t be fooled by instruments that only sample results instead of reading them. A snap shot of a system’s performance, through traditional or digital means,
is not actual combustion testing. The Smart Bell provides instantaneous and continuous reading while adjustments are being made giving you real-time results and saving precious time.

Features:

• Real Time Analysis
• NEW EOS Technology - Electro-Optical Sensor lowers the cost of ownership by doing away with the annual replacements of the O₂ sensor and reducing calibration drifting typically found with standard electro-chemical sensors. This long life sensor is warranted for 5 years and has an unmatched industry-leading life expectancy of 10 years
• Direct CO₂ measurements
• In-line water trap
• Extended long life CO₂ sensor
• Measures:
  • CO₂ Carbon Dioxide
  • Flue Temperature
• Calculates:
  • O₂
  • Efficiency
  • Excess Air
  • Net Temperature
• Pre-Programmed Fuels
  • Light Oil
  • Propane
  • Natural Gas
  • Heavy Oil
  • Wood

Specifications:

• Dimensions:
  • Meter: 7" x 2" x 31/4"
  • Probe: 4" x 1/4" stainless steel shaft with nominal 36" neoprene hose
• Weight 1lb
• Operating temperature range: 32°F to 104°F
• Operating humidity range: 10% to 90% RH non- condensing
• Operating atmospheric pressure range: 850 to 1100 mmHg
• Power: (4) AA cells
• Battery life: >8 hours using Alkaline AA batteries

Supplied with:

• Probe
• Storage case
• Owner’s manual
• Quick start guide
• 5 year limited manufacturer's warranty

Download User's Manual (PDF format)
