Honeywell Analytics XD H2S Detector (XD-HN) 0-100ppm H2S Sensor

Reference only — not for sale

Model	XD-HN
Manufacturer	Honeywell
Category	Leak Detectors
Status	Discontinued

Browse all Leak Detectors Ask us for a replacement

Product details (archived)

The information below is retained for reference only. This item is discontinued and cannot be ordered.

Honeywell XD Hydrogen Sulfide (Range: 0-100ppm) detectors are IP66/67 rated and fully immersible with EMI/RFI resistant housing and a built-in concussion-proof boot. An extra-loud audible alarm, flashing LED light bars, and internal vibrator alerts users to hazardous conditions.

The Honeywell XD single gas detector clearly warns users of present gas hazards: Low, High, TWA, and STEL gas alarm. Recorded TWA, STEL, and peak exposures can be displayed on demand. Honeywell XD single gas detectors have datalogging, multi-language support, and a built-in IR COM port for automatic data transfer to a computer or MicroDock II docking station module. No wires are necessary!

Sensor: electromechanical (replaceable)
Hydrogen Sulfide detection range: 0 to 100ppm
Operating temperature range: -40 degrees to 122 degrees F
Operating humidity range: 15 to 90% RH, non condensing
Simple auto-zero and calibration
Low, High, TWA and STEL alarms with adjustable set-points
Audible, vibrating and visual alarms
Audible Alarm/Indicators: Two levels
- High-output, pulsing 95 dB at 1 foot
- Periodic confidence beep every 5 seconds (field selectable on/off)
Vibrating Alarm: Vibrates in sync with audible and visual alarms
Visual alarm: 4 High-intensity red LEDs, plus alarm LCD readout
Self checks for sensor, battery and circuitry integrity
Calibration: Automatic (stand alone or with MicroDock II)
Water and dust-resistant IP66/67 rating
Built-in concussion-proof boot (ruggedized)
Plug-in easy to replace sensor
LCD shows real-time gas concentration
Ultra-clear backlit display
UL, cUL, ATEX, IECEx approvals
Compact and affordable
Event Logging: Records and transmits up to 10 gas alarm events. Event information: gas type, peak exposure level (ppm or %vol); alarm duration in minutes and seconds; time elapsed since the alarm occurred in days, hours and minutes. Transmission method: via infrared port to USB PC adapter.
Intrinsic Safety Approvals: UL, cUL; ATEX, IECEx
Power: 3v replaceable lithium battery
Battery life: approximately two years of continuous operation
Dimensions: 1.1" x 2" x 3.75" (28 x 50 x 95mm)
Weight: 2.9 oz. (82 grams)
Warranty: 2 years including sensor

Supplied with:

Heavy-duty, alligator-style belt-clip (non-conductive)
Lithium battery
Users manual
Calibration Certificate

Other XD models:

Ammonia (Range: 0-400ppm) XD-AN
Carbon Monoxide (Range: 0-1000ppm) XD-MN
Chlorine (Range: 0-50ppm) XD-CN
Hydrogen Cyanide (Range: 0-30ppm) XD-ZN

Hydrogen Sulfide (Range: 0-500ppm) XD-H2N
Oxygen (Range: 0-30%) XD-XN
Phosphine (Range: 0-5ppm) XD-PN
Sulphur Dioxide (Range: 0-100ppm) XD-SN
