Honeywell XD Hydrogen Cyanide Detector (XD-ZN) 0-30ppm HCN

Model #: XD-ZN

Condition: New

This item is No Longer Available

No Longer Available
Product 12 of 12

Honeywell XD Hydrogen Cyanide detectors are IP66/67 rated and fully immersible with EMI/RFI resistant housing and a built-in concussion-proof boot. An extra-loud audible alarm, flashing LED light bars, and internal vibrator alerts users to hazardous conditions.

The Honeywell XD single gas detector clearly warns users of present gas hazards: Low, High, TWA, and STEL gas alarm. Recorded TWA, STEL, and peak exposures can be displayed on demand. Honeywell XD single gas detectors have datalogging, multi-language support, and a built-in IR COM port for automatic data transfer to a computer or MicroDock II docking station module. No wires are necessary!

  • Sensor: electromechanical (replaceable)
  • Hydrogen Cyanide detection range: 0 to 30ppm
  • Operating temperature range: -40º to 122º F
  • Operating humidity range: 15 to 90% RH, non condensing
  • Simple auto-zero and calibration
  • Low, High, TWA and STEL alarms with adjustable set-points
  • Audible, vibrating and visual alarms
  • Audible Alarm/Indicators: Two levels
    • High-output, pulsing 95 dB at 1 foot
    • Periodic confidence beep every 5 seconds (field selectable on/off)
  • Vibrating Alarm: Vibrates in sync with audible and visual alarms
  • Visual alarm: 4 High-intensity red LEDs, plus alarm LCD readout
  • Self checks for sensor, battery and circuitry integrity
  • Calibration: Automatic (stand alone or with MicroDock II)
  • Water and dust-resistant IP66/67 rating
  • Built-in concussion-proof boot (ruggedized)
  • Plug-in easy to replace sensor
  • LCD shows real-time gas concentration
  • Ultra-clear backlit display
  • UL, cUL, ATEX, IECEx approvals
  • Compact and affordable
  • Event Logging: Records and transmits up to 10 gas alarm events. Event information: gas type, peak exposure level (ppm or %vol); alarm duration in minutes and seconds; time elapsed since the alarm occurred in days, hours and minutes. Transmission method: via infrared port to USB PC adapter.
  • Intrinsic Safety Approvals: UL, cUL; ATEX, IECEx
  • Power: 3v replaceable lithium battery
  • Battery life: approximately two years of continuous operation
  • Dimensions: 1.1" x 2" x 3.75" (28 x 50 x 95mm)
  • Weight: 2.9 oz. (82 grams)
  • Warranty: 2 years including sensor

Supplied with:

  • Heavy-duty, alligator-style belt-clip (non-conductive)
  • Lithium battery
  • Users manual
  • Calibration Certificate

Other XD models:

Ammonia (Range: 0-400ppm) XD-AN
Carbon Monoxide (Range: 0-1000ppm) XD-MN
Chlorine (Range: 0-50ppm) XD-CN

Hydrogen Sulfide (Range: 0-100ppm) XD-HN
Hydrogen Sulfide (Range: 0-500ppm) XD-H2N
Oxygen (Range: 0-30%) XD-XN
Phosphine (Range: 0-5ppm) XD-PN

Sulphur Dioxide (Range: 0-100ppm) XD-SN

Download Honeywell Analytics XD Single Gas Detector Brochure (PDF format)

Download Honeywell Analytics XD Single Gas Detector Data Sheet (PDF format)
