Lutron LCR Meter (LCR-9186SD)

Reference only — not for sale

Model	LCR-9186SD
Manufacturer	Lutron Instruments
Category	Multimeters / LCR
Status	Discontinued

Browse all Multimeters / LCR Ask us for a replacement

Product details (archived)

The information below is retained for reference only. This item is discontinued and cannot be ordered.

Lutron LCR Meter (LCR-9186SD)

SD card real time data recorder.

Features:

Real time Datalogger, save the into the SD memory card and can be downloaded to the Excel, extra software is no need.
Real time Datalogger, it Built-in Clock (year/month/date/ hour/minute/second ), sampling time set from 2 seconds to 3600 seconds.
Manual datalogger is available ( set the sampling time to be 0 second ).
6000 counts ADC resolution.
High performance analog front end for impedance(Z) measurement.
Support Z / DCR measurement for LCR mode.
Four different test frequency are available : 100 Hz/120 Hz/1 KHz/10 KHz for L/C/R measurement.
Test AC signal level : 0.5 V rms typically.
Test range : ( ex. F = 1 KHz ) L : 600.0 uH to 60.00 H C : 600.0 pF to 600.0 uF R : 60.00Ω to 20.00 MΩ
Min. source resistance : 120Ω typical.
6 ratio resistor range used for LCR mode.
