Reference only — this item is no longer available. This product has been discontinued and cannot be ordered. We keep the page online so the specifications and documentation stay available to anyone still running the equipment. Current replacements are listed further down.

Discontinued

UEI Combustion Analyzer O2 CO2 & CO (C127) SS Probe, Hose & Case

Reference only — not for sale

Model	C127
Manufacturer	UEI
Category	Leak Detectors
Status	Discontinued

Browse all Leak Detectors Ask us for a replacement

Product details (archived)

The information below is retained for reference only. This item is discontinued and cannot be ordered.

The C127 Combustion Analyzer by UEI is 4 instruments in 1. Designed to offer advanced system analysis and productivity. This multi-functional instrument is a superior combustion analyzer with unmatched simplicity and a unique combination of features to enhance a technician's efficiency and safety. The Eagle 3 is perfect for combustion efficiency analysis but also doubles as a differential thermometer, differential manometer, and an ambient CO detector. Offers the same benefits of the Eagle 2 (C125) with the additional ability to measure Nitric Oxide (NOx). This allows technicians to work in commercial and light industrial applications measuring Nitric Oxide at 1ppm resolution.

Measures flue temperature, oxygen, carbon monoxide (CO), Differential and Nitric Oxide (NOx)
Calculates: Carbon dioxide CO2 , gross / net efficiency, excess air, CO air free
Built-in Worklight
Unique DMM style rotary selector
Protective boot with integral magnet
Real time clock with date & time stamp
CO readings to 1ppm
Large 4 line back-lit display
User programmable header
179 memory position
User customizable parameters view
Individual report printouts
Infrared printer port

Specifications:

Flue & Inlet Temp Range: 20° to 2400°F (-29° to 1315°C)
Inlet Temp Range (Ambient): 32° to 122°F (0° to 50°C)
Net Temp (DELTA T):** 20° to 2400°F (-29° to 1315°C)
Resolution: 0.1°
Flue (T1, Inlet T2, & Net DELTA T) Accuracy: ±[0.3% reading + 3.6°F (2°C)]
Inlet Temp Ambient Accuracy: ±[0.3% reading + 1.8°F (1°C)]
Oxygen O2: 0 to 21%
Carbon Monoxide CO: 0 to 2000ppm (4000 max 15 min)
Carbon Dioxide CO2: 0 to 30%
Efficiency: 0 to 99.9%
Excess Air: 0 to 250%
Excess Air Resolution/Accuracy: 0.1% / ±0.2% reading
CO/CO2: 0 to 0.999%
Nitric Oxide NOx: 0 to 100ppm
Weight: 2.2lbs. with boot
Handset: 7.9" x 1.8" x 3.5"
Probe: 11.8" x 0.25" x 9.4" stainless steel shaft, type K thermocouple (9' hose)
Operating temperature range: 32° to 104°F (0° to 40°C)
Operating humidity range: 10 to 90% RH non-condensing
Power: 4 AA cells / 12 hour life typical with Alkaline AA cells
Pre-Programmed Fuels: A Natural Gas, Propane, Butane, LPG, Light Oil
