TPI Digital Air Velocity/Air Flow Meter (556C1)

TPI Digital Air Velocity/Air Flow Meter (556C1)

Digital vane air velocity, calculate CFM and temperature. The 556 Digital Air Velocity Meter is a state of the art, easy to use instrument designed to provide temperature and air velocity readings as well as calculating CFM.

The 556 Digital Air Velocity Meter is a state of the art, easy to use instrument designed to provide temperature and air velocity readings as well as calculating CFM. The instrument is ruggedly constructed and comes with a 3 Year Guarantee.

The TPI 556 Digital Air Velocity Meter comes complete with the following items as standard:

• Measure air velocity, air flow and temperature.
• Five units of measure for air velocity: (m/s, km/hr, mile/hr, knots, ft/min).
• Two units of measure for air flow: (cfm, cmm).
• Send real time and logged data to a PC via optional A500 interface cable.
• Four digit dual line display simultaneously shows air flow and temperature.
• Data record displays minimum, maximum and average readings.
• Data log up to 1000 readings in 1 second to 999 second intervals.

Specifications

• Air Velocity (Low friction ball conventional twist wheel): 80 to 5916 ft/min 0.4 to 30 m/s.
• Units of Measure: m/s, km/s, ft/min, mile/hr, knots.
• Air Velocity Accuracy: ±(1% of rdg + 3 digits).
• Temperature (Precision thermistor): -5°F to 175°F -20°C to 80°C.
• Temperature Accuracy: ±(1% of rdg + 1°F + 3 digits).
• Units of Measure: °C / °F.
• CFM Calculation: Automatic (Input duct size through keypad).
• RS-232 Output: Yes.
• Min/Max Record: Yes.
• Operating Temperature (Base Unit): 32°F to 122°F.
• Operating Humidity (Base Unit): <80% non-condensing.
• Battery Type: AAA (6).
• Battery Life: 30 hours typical.
• Dimension W x L x H: 2.9" x 5.7" x 1.1".
• Weight: 0.3lb.
